Cobra 29 LTD CLASSIC

29 LX MAX

Download Manual



The Cobra 29LXMAX transceiver represents one of the most advanced AM two-way radios used as a Class D station in the Citizens Radio Service. This unit features advanced Phase Lock Loop (PLL) circuitry providing complete coverage of all 40 CB channels.

 Features

  • Selectable 4-Color LCD Displayy
  • Advanced Bluetooth ® Connectivity
  • Rewind-Say-Again®
  • Memo Record
  • iRadar App Integration
  • Report Feature
  • NightWatch® Illumination
  • 10 Weather Channels
  • Weather Scan
  • Emergency Weather Alert
  • 40 CB Radio Channels
  • 40 Channel Scan
  • Memory Channels
  • Channel Frequency Read-Out
  • Radio Check Diagnostic
  • Clock/Timer/Alarm
  • Multi-Function Heavy-Duty Electret Microphone with Phone, Rewind-Say-Again® & Report Functions
  • Full 4 Watts AM RF Power Output
  • SWR Calibration Meter
  • Instant Channel 19 and 9
  • Front Panel 6-Pin Microphone Connector
  • Switchable Automatic Noise Limiter & Noise Blanker
  • Adjustable Dynamike Boost
  • Tactile Controls
  • 9 Ft Mic Cord
  • Programmable Dimmer Control
  • RF Gain
  • External Push-To-Talk Jack
  • External Microphone Jack

Bluetooth® Features

  • Dual Point Bluetooth®
  • Caller I.D.
  • A2DP Audio Streaming
  • Phone Directory

























... Cobra 29 LX MAX...

$199.95





Optional Accessories

Tune-up. 25-30 W peak power (perform a tune-up to radio to increase power, audio and performance)  AM carrier 5-6 watts and 25-30 watts peak power. $29

 NEW MOSFET Final. (perform a tune-up to radio to increase power, audio and performance and replace the bipolar transistor final with a higher power MOSFET) AM carrier 5 watts and 32-38 watts peak power. $59

Fan Options


SOLD OUT
 RFX-85 Final. (perform a tune-up to radio to increase power, audio and performance and replace the bipolar transistor final with a completely new final section consisting of even higher power MOSFETs)
AM carrier 15 watts and 75+ watts peak power.

SOLD OUT
 RFX-150 Final. (perform a tune-up to the radio.  Increase power, audio and performance and a completely new final section consisting of even higher power MOSFETs) AM carrier 35 watts and 125+ watts peak power. $185

RFX-150 FAN KIT Installed Install FOUR - 30 x 30 x 10mm Black Fans with a switch for on/off combined with the amp on/off switch. $69

 Perform Receiver improvement mods.
(These mods replace key RX parts for better sensitivity and lower noise)
$26

 Install a Lescomm 120 Channel Frequency Kit
(This mod adds a 3 position switch or you can use the NB/ANL switch to access 120 channels) Tune-up Included.
$119
 Install an Echo board. (BACK or SIDE)
(wired internal to the radio with dual controls on the side or back to control speed and echo effects TRB-X2/X3 Echo board)
$65
 Install an Echo board. (FRONT)
(wired internal to the radio with dual controls in the Delta tune slot to control speed and echo effects With matching cobra control knobs)
$80

 Install a Roger Beep tone board.
(wired inside the radio with a switch for on/off)
$79
Sound Byte link
 Install a Noise toy
(wired inside the radio with a switch or pushbutton to trigger any 18 second sound byte you want)
$65
Sound Byte link
 Install a Noise toy as a background theme music
(wired inside the radio with a switch to play any background music at very low volume so you can talk over it.)
$65

  Install a Record/Playback Module 18 seconds (wired inside the radio with  a switch on the side to record 18 seconds and to play it back) $77
 Add a Small External Speaker
(plugs into back of the radio for improved sound)
$12
 Add a Large External Speaker
(plugs into back of the radio for improved sound)
$18
Colors
Install Nitro Knobs with dimmer control. Includes a 6 Knob set , parts and labor. $154

Your Gmail

Tune-up VIDEO. Make a completion video to show tune-up levels and modifications demo. Enter your Gmail so we can send a share to our Google drive for you to view. We upload twice monthly. $19





SPECIFICATIONS
Unit Dimensions: 7-1/4 x 2-1/4 x 8-5/8
Microphone Type: 4 Pin Screw-On Dynamike
Frequency Control: Phase Lock Loop Synthesizer
RF Output Power: 4 Watts (Maximum FCC allowed)
CB Channels: 40 Channels (26.965 to 27.405 MHz)
Individual Carton
Dimension: (in)
11-7/8 x 13-1/8 x 2-3/4



Selectable 4-Color LCD Display Choose from four easy-to-read display colors: red, blue, green and amber.
10 NOAA Weather Channels Instant access to 10 National Weather Channels, 24 hours a day, in all 50 states.
Emergency Weather Alert Alerts you if threatening weather is nearby with an alert tone even if CB is turned off.
Talk Back This control is used to adjust the desired amount of modulation talk back that is present at the speaker during transmit
Weather Alert Scan Automatically scans for the nearest weather alert signal.
Radio Check Diagnostic Allows testing of important radio functions such as RF power, antenna condition and battery voltage.
Memory Channel Scan Allows scanning of up to 10 channels stored in memory.
Memory Channels Stores up to 10 frequently used channels.
Selectable Key Tone Allows key tone to be turned on or off.
Day / Night Dimmer Control Adjusts brightness of the front panel for day and night driving.
SWR Calibration Allows calibration of antenna system for maximum performance.
Channel Scan Allows scanning of all 40 channels.
Auto Weather Scan Automatically scans for the weather band for the strongest signal.
Frequency Display Displays operating channel frequency of CB and weather band.
9 Foot Microphone Cord For easy reach within any area of the vehicle.
4-Pin Front Microphone Connector Allows convenient installation to be in dash or under dash.
Adjustable Dynamike Boost Dynamically boosts microphone for increased voice clarity.
Tactile Controls Allows you to actually feel where the dial is in it's rotation without taking your eyes off the road.
PA Capability Use CB radio as a Public Address System with PA speaker. Receive signals can also be monitored through PA.
RF Gain Adjusts receive gain in weak and strong signal areas.
Switchable Noise Blanker For increased noise reduction.
Dimmer Control Adjusts brightness of the front panel, channel display and signal strength meter.
4 Watts AM RF Power Output The maximum allowed by law.
Antenna Warning Indicator Illuminates when antenna needs checking.
Instant Channel 9 and 19 Instant access to emergency channel 9 and information channel 19.
Delta Tune Used to clarify incoming signals









Cobra 2 Year Warrantee

For Operational or Technical Assistance with a Cobra Product call Cobra at 1-773-889-3087. You'll find answers to many of your questions in our Their FAQ's section. Cobra's automated help desk is available 24 hours a day 7 days a week. Live operators are available Monday through Friday 8 AM to 8 PM CST



The item most overlooked when ordering a custom radio is the microphone.  Your new tuned radio will NOT
sound great  with a stock mic on it  If your CB is more than a tool for work, you NEED to upgrade your microphone.
My personal favorites are the Astatic 636L and RD104E.

If you place an order from outside the continental USA, we will calculate your actual shipping and send you a PayPal payment request.  We do NOT export Antennas or Base station radios.
