Uniden PC-78LTX CB Radio
Uniden PC-78LTX CB Radio - Image 2
Uniden PC-78LTX CB Radio - Image 3
Uniden PC-78LTX CB Radio - Image 4
Uniden PC-78LTX CB Radio - Image 5

Videos

.

,

Uniden PC-78LTX CB Radio

More information

Download Manual

The Uniden PC78LTX has set the standard for professional driver CB communications. Its compact design can fit perfectly in the overhead console of your truck or on the dash of any vehicle.
Key notable features include an integrated SWR Antenna Calibration system that allows you to calibrate the vehicle’s antenna system for optimum receive and transmit performance. This CB Radio also includes Antenna Warning LED, RF Gain, Microphone Gain, Hi Cut noise reduction, Automatic Noise Limiter, Noise Blanker, and a PA System. This CB Radio continues to be the number one choice of professional drivers and truckers.
Hit the road in trucker’s style with the Uniden PC78LTX CB Radio. Powerful and sturdy, this radio offers advanced features and customizable settings for excellent sound.Classic looks with easy to use controls..Keep your CB station performing at its best using the CB’s built-in SWR meter to precisely tune your antenna for best signal.

Box Includes

  1. PC78LTD CB 2-Way Mobile Radio
  2. Microphone
  3. Mounting Bracket Kit
  4. DC Power Cord
  5. Owner’s Manual
  6. Part 95 Sub part D (FCC rules)

Features

  • INTEGRATED SWR ANTENNA CALIBRATION
    Keep your CB station performing at its best using the CB’s built-in SWR meter to precisely tune your antenna for best signal.

  • 40 CHANNEL OPERATION
    Enjoy the complete range of 40 CB radio channels to communicate with those around you.

  • HIGH-CUT AUDIO
    Cuts out the high frequency interference for clear receive.

  • RF GAIN & MIC GAIN
    Adjusts receiver sensitivity for better reception and microphone sensitivity for 100% modulation.

  • AUTOMATIC NOISE LIMITER
    Automatic Noise Limiter and Noise Blanker reduces external noise, and ignition interference.

  • 50th Anniversary Edition
  • PA/CB Switch
  • SWR Meter for Antenna Tuning
  • LED Display
  • Channel Knob to Select Transmission and Reception Channel
  • Squelch Control
  • DC Cord
  • Analog S/RF Meter
  • Microphone
  • Extra Long Mic Cord
  • Instant Channel 9
  • Volume Control
  • External Speaker Capability
  • NEW SURFACE MOUNT DESIGN

GENERAL

click to review tech spec's

Radios requiring technical services may be delayed 3 to 7 days

Optional accessories

Select all the accessories you would like added to this product, then select add to cart.

Choose from the many upgrades below BEFORE clicking add to cart

Radios requiring technical services may be delayed 3 to 7 days

$149.50

upgrade performance

Tune UP
Tune-up
(perform a tune-up to radio to increase power, audio and performance)
(+$29.50)
VARIABLE POWER
VARIABLE POWER
Install a power regulator / super modulator circuit and a front panel control installed in the delta tune location. Smooth Variable AM carrier from 1/2w to 5 watts. Includes a full Tune and Alignment to the radio.
(+$79.50)
Change factory power cord
Change factory power cord
to a 10 Gauge Power Cord (14 foot) and modify the DC Jack for high amperage 2 Pin Quick connector.
(+$59.50)

Other Upgrades

Install a Record/Playback Module
Install a Record/Playback Module
Radio on Air Recorder Installed
$89.00

Install an Echo Board (BACK or SIDE)

(Wired internal to the radio with dual controls to control speed and echo effects)

Install Talkback

(wired inside the radio so that when you talk you can hear yourself. If you chose an Echo or a Recorder mod, I highly suggest this as well)

Install a Noise toy

Wired inside the radio with a switch or pushbutton to trigger any 18 second sound byte you want.

upgrade Microphone

RK-56B Microphone
Turner RK-56 Noise Canceling microphone
(+$46.50)
636L Noise Canceling Microphone
636L Noise Canceling Microphone
(wired for this radio with a 4 pin plug)
(+$34.50)

Upgrade speaker

Add a Small External Speaker
Add a Small External Speaker
(plugs into back of the radio for improved sound)
(+$12.00)
Add a Large External Speaker
Add a Large External Speaker
(plugs into back of the radio for improved sound)
(+$25.00)
Order total:

Optional Accessories

Recommended For You

Related products

Popup code

Scroll to Top

GENERAL

Channel:40
Frequency Range:26.965 - 27.405 MHz
Weather Frequencies:162.400 MHz (WX CH1) 162.425 MHz (WX CH2) 162.450 MHz (WX CH3) 162.475 MHz (WX CH4) 162.500 MHz (WX CH5) 162.525 MHz (WX CH6) 162.550 MHz (WX CH7)
Frequency Control:PLL Synthesizer
Antenna Impedance:50 ohms
Power lnput:13.8 VDC
Current DrainTX: AM Full Modulation 2.2 A max) RX: Squelch 0.4 A (NOMINAL)
Operating Temperature:-30°C to 50°C (CB) -10°C to 50°C (WX) -10°C to +50°C (DSC on)
Accessories:DC Power Cord Microphone Microphone Hanger Mounting Bracket
Size (W x D x H):160mm x 217mm x 55mm (6.3"x8.49"x2.17")
Weight:1.7 kg
TRANSMITTER
Output Power:4 watts
Emission Type:6A3
Hum and Noise:Better than 40 dB
Frequency Tolerance:±0.002%
Modulation Percentage (Peak):100%
Spurious Rejection:-70 dB
Output Impedance:50 ohm, unbalanced
RECEIVER
Sensitivity at 10 dB S+N/N:0.5 μV
Sensitivity at 500 mW Audio Output: 0.5 μV
Squelch Threshold:0.5 μV
Antenna Impedance:50 ohms
Squelch Tight:1000 μV
Signal Meter S-9:100 μV
Audio Output Power (max.):5 watts
Audio Output (10% Dist.):4 watts
Selectivity @ 6 dB Down:7 kHz
Adjacent Channel Rejection:70 dB
Image Rejection:90 dB
Internal Speaker Impedance16 ohms
External Speaker Impedance:8 ohms
PUBLIC ADDRESS
Output Power at 10% Distortion:4 watts
