Uniden PC-68LTX CB Radio
Uniden PC-68LTX CB Radio - Image 2
Uniden PC-68LTX CB Radio - Image 3
Uniden PC-68LTX CB Radio - Image 4
Uniden PC-68LTX CB Radio - Image 5

Videos

.

, ,

Uniden PC-68LTX CB Radio

More information

Download Manual

The Uniden PC68LTX operates on any of the 40 AM frequencies authorized by the FCC. It comes with key features like Squelch Control and Active Noise Limiter that allows for high quality sound and less pulse noise resulting in crisp communication and transmission.

The bright LED channel indicator is easy to read and combined with a long mic, makes communicating while on the road easier and more efficient. Microphone adjustments to the gain allows for better control over the mic sensitivity. All in all, an excellent choice for truckers and CB radio enthusiasts.

Features

  • 40 Channel Operation
    Enjoy the complete range of 40 CB radio channels to communicate with those around you.

  • High-Cut Audio
    Cuts out the high frequency interference for clear receive.

  • RF Gain & Mic Gain
    Adjusts receiver sensitivity for better reception and microphone sensitivity for 100% modulation.

  • Public Address (PA) System
    Connects to an external PA speaker for amplified announcements.

  • Automatic Noise Limiter
    Automatic Noise Limiter and Noise Blanker reduces external noise, and ignition interference.

  • High quality circuitry.
  •  Styled and packed with the most popular 2-way radio features in a user friendly package.
  • Bright LED channel indicator, easy to read meter, front panel Mic connector, and enhanced channel selector that offers more positive channel selection and reduced drift.
  • Extra-long mic cord for operator convenience.
  • RF gain control
  • Mic gain control
  • PA/CB switch
  • Analog S/RF meter
  • instant access to channel 9
  • Sturdy mic with left side positive push to talk
  • NEW SURFACE MOUNT DESIGN
    This is not a release old the old version, it is all new with micro surface mount technology.

GENERAL

click to review tech spec's

Radios requiring technical services may be delayed 3 to 7 days

Optional accessories

Select all the accessories you would like added to this product, then select add to cart.

Choose from the many upgrades below BEFORE clicking add to cart

Radios requiring technical services may be delayed 3 to 7 days

$139.50

upgrade performance

Tune UP
Tune-up
(perform a tune-up to radio to increase power, audio and performance)
(+$29.50)
VARIABLE POWER
VARIABLE POWER
Install a power regulator / super modulator circuit and a front panel control installed in the delta tune location. Smooth Variable AM carrier from 1/2w to 5 watts. Includes a full Tune and Alignment to the radio.
$79.00

Other upgrades

Install an Echo Board (SIDE)

(Wired internal to the radio with dual controls in the front to control speed and echo effects)

Install Talkback

(wired inside the radio so that when you talk you can hear yourself. If you chose an Echo or a Recorder mod, I highly suggest this as well)

Install a Noise toy

Wired inside the radio with a switch or pushbutton to trigger any 18 second sound byte you want.

upgrade Microphone

RK-56B Microphone
Turner RK-56 Noise Canceling microphone
(+$46.50)
636L Noise Canceling Microphone
636L Noise Canceling Microphone
(wired for this radio with a 4 pin plug)
(+$34.50)

Upgrade speaker

Add a Small External Speaker
Add a Small External Speaker
(plugs into back of the radio for improved sound)
(+$12.00)
Add a Large External Speaker
Add a Large External Speaker
(plugs into back of the radio for improved sound)
(+$25.00)
Order total:

Optional Accessories

Recommended For You

Related products

Popup code

Scroll to Top

GENERAL

Channel:40
Frequency Range:26.965 - 27.405 MHz
Weather Frequencies:162.400 MHz (WX CH1) 162.425 MHz (WX CH2) 162.450 MHz (WX CH3) 162.475 MHz (WX CH4) 162.500 MHz (WX CH5) 162.525 MHz (WX CH6) 162.550 MHz (WX CH7)
Frequency Control:PLL Synthesizer
Antenna Impedance:50 ohms
Power lnput:13.8 VDC
Current DrainTX: AM Full Modulation 2.2 A max) RX: Squelch 0.4 A (NOMINAL)
Operating Temperature:-30°C to 50°C (CB) -10°C to 50°C (WX) -10°C to +50°C (DSC on)
Accessories:DC Power Cord Microphone Microphone Hanger Mounting Bracket
Size (W x D x H):160mm x 217mm x 55mm (6.3"x8.49"x2.17")
Weight:1.7 kg
TRANSMITTER
Output Power:4 watts
Emission Type:6A3
Hum and Noise:Better than 40 dB
Frequency Tolerance:±0.002%
Modulation Percentage (Peak):100%
Spurious Rejection:-70 dB
Output Impedance:50 ohm, unbalanced
RECEIVER
Sensitivity at 10 dB S+N/N:0.5 μV
Sensitivity at 500 mW Audio Output: 0.5 μV
Squelch Threshold:0.5 μV
Antenna Impedance:50 ohms
Squelch Tight:1000 μV
Signal Meter S-9:100 μV
Audio Output Power (max.):5 watts
Audio Output (10% Dist.):4 watts
Selectivity @ 6 dB Down:7 kHz
Adjacent Channel Rejection:70 dB
Image Rejection:90 dB
Internal Speaker Impedance16 ohms
External Speaker Impedance:8 ohms
PUBLIC ADDRESS
Output Power at 10% Distortion:4 watts
