Mirage MX-36HP3 AM 10M Mobile Radio
Mirage MX-36HP3 AM 10M Mobile Radio - Image 2
Mirage MX-36HP3 AM 10M Mobile Radio - Image 3
Mirage MX-36HP3 AM 10M Mobile Radio - Image 4
Mirage MX-36HP3 AM 10M Mobile Radio - Image 5

Videos

.

, ,

Mirage MX-36HP3 AM 10M Mobile Radio

More information

The Mirage MX-36HP3 radio is a new radio from the folks at Ranger Communications. The MX-36HP3 is a DX radio that will fit in the Cobra 29LTD size holes. Very nice for those with a spot just right for a Cobra 29LTD (many standard holes in tractors are made for the Cobra 29 size).

Ranger radios sometimes have a small scratch or ding that the factory covers with black touch up. We can NOT affect this and do not guarantee your radio to be cosmetically perfect. Bells CB will make no marks or scratches on your radio ourselves. Ranger might though and we cannot control this.



Features

  • Classic Chrome Design
  • 7 1/4″ Size Chassis (29 Size Chassis)
  • AM Mode
  • NB/ANL Switch
  • 60+ watts PeP  OUTPUT Power
  • Variable RF Power Control
  • S/RF/SWR Front Panel Meter
  • 4pin Front Panel Mic Jack
  • Comes with a SRA-198 Noise Cancelling Mic Included
  • Variable Echo and Talk Back Controls
  • 3 Position Dimmer Switch
  • Cool Blue LED Channel Display

Specifications

click to review tech spec's

Radios requiring technical services may be delayed 3 to 7 days

Optional accessories

Select all the accessories you would like added to this product, then select add to cart.

Choose from the many upgrades below BEFORE clicking add to cart

Radios requiring technical services take 7-14 business days from date of order.

$249.50

Upgrade Performance

Tune UP
Tune-up, Alignment and Frequency conversion
Perform a tune up, alignment, and expanded frequency conversion to the radio.
$39.50
Perform Receiver Improvement Modification
Perform Receiver Improvement Modification
These mods replace key RX parts for better sensitivity.
$26.00
CP-1 Compressor
Install an CP-1 Top Gun Audio Compressor
(on - all the time) Is most noticed on SSB, This amplifies your lower level audio on transmit. NOTE: It becomes difficult to use the Talkback even at low volume with this mod.
$25.00

Install a Noise toy

(wired inside the radio with a switch or pushbutton to trigger any 18 second sound byte you want)

other upgrades

Install a Record/Playback Module
Install a Record/Playback Module
Wired inside the radio with two push buttons on the side to record 120 seconds and to play it back.
(+$77.50)

Сhange the appearance

Chrome Covers
Chrome Covers
Exchange the top and bottom covers to Chrome Covers.
(+$32.50)
Diamond Plate Covers
Diamond Plate Covers
Exchange the top and bottom covers to Diamond Plate Covers
(+$29.50)

Install Star-Bryte Knobs

Install Star-Bryte Knobs with dimmer control circuit integrated into the radios dimmer. Includes a 6 Knob set, parts and labor. The picture shows blue as an example, whatever color you choose will be the color you get.

Install Star-Bryte Rings ONLY (no knobs)

Install Star-Bryte Rings BEHIND the factory knobs with dimmer control circuit integrated into the radios dimmer. Includes a 6 LED Rings, parts and labor. The picture shows blue as an example, whatever color you choose will be the color you get.

Upgrade Microphone

Astatic 636L Noise Canceling microphone
Astatic 636L Noise Canceling microphone
(+$34.50)
RK-56B Microphone
Turner RK-56B Noise Canceling microphone
Pre-wired with high quality 4 pin Plug for Cobra / Uniden / President / Galaxy / Radio Shack / Ranger
(+$46.50)
D104-M6 Amplified Microphone
D104-M6 Amplified Microphone
Amplified microphone (wired 4-pin and a Duracell battery added)
$59.50

Upgrade speaker

Add a Small External Speaker
Add a Small External Speaker
(plugs into back of the radio for improved sound)
$12.00
Add a Large External Speaker
Add a Large External Speaker
(plugs into back of the radio for improved sound)
$25.00
Order total:

Optional Accessories

Recommended For You

Related products

Popup code

Scroll to Top

Specifications

General
Frequency Range 28.145 - 29.655 MHz
Modes AM
Frequency Control PLL Synthesizer
Frequency Stability 0.001%
Operating Temp. Range - 30 ºC to + 50 ºC
Input Voltage 13.8 Vdc
Antenna Impedance 50 Ohms
Size (W x D x H) 7-3/8(W) x 8-3/4(D)x 2-1/4 (H)
Weight 3.5 Lbs.
Shipping Weight 6 Lbs.
Transmitter
RF Power Output AM: 10W 25W PEAK
Spurious EmissionBetter than -50 dB
Audio Distortion 10 %
Frequency Response 300 to 2500 Hz
Microphone Dynamic
Receiver
AM Sensitivity for 10 dB SINAD 0.5 µV
Squelch Sensitivity 0.5 µV
Image Rejection - 50 dB
Audio Response 300 to 2500 Hz
