| These mounts were specifically
designed to allow antenna installations on vehicles where other mounts may
not work. The primary goal was to offer a mount that could be affixed to a
vertical inner door jamb such as that which might be found on the rear or
side door of a cargo type van. Since the mounting screws are meant to be on
the inner edge of the jamb, visible holes in the vehicle body are
eliminated. Chances are, you will find several locations to mount it
on your vehicle. For antennas up to 4ft in length.
In order to give you many years of trouble
free use, the bracket parts and mounting hardware are made of
stainless steel. The bracket is 1.5" (38mm) wide and has a 2" (50mm)
reach for mounting inside the door jamb. Overall, the mount is 4.2"
(105mm) long. In order to compensate for the door jamb angles, the
stud bracket will swivel a full 180 degrees, 90 in each direction.
This adjustment feature will let you mount the antenna on either the
left or right side of the vehicle.
The SS-204A includes the K-4A antenna stud mount
with a screw on coax connector (SO-239).
Reversible !!
|
